JIS B2220 Socket Welding Flange
Keyword:
Product Detail
standard
Product introduction
Socket Weld (SW) Flanges are a type of pipe flange designed for use in high-pressure and small-diameter piping systems. They are commonly used in applications where leakage prevention and structural integrity are critical. Here are some key features and details about SW flanges:
1. Design:
- SW flanges have a socket-like recess at the base, which allows the pipe to be inserted into the flange before welding.
- The pipe is then fillet-welded around the outer edge of the flange, creating a strong and leak-proof connection.
2. Applications:
- Ideal for small-diameter pipes (typically up to 4 inches or DN100).
- Commonly used in high-pressure systems, such as hydraulic, steam, and chemical processing industries.
3. Advantages:
- Provides excellent flow characteristics due to the smooth bore and reduced turbulence.
- Offers high structural integrity and resistance to leakage.
- Suitable for high-pressure and high-temperature environments.
4. Limitations:
- Not recommended for corrosive or erosive fluids, as the gap between the pipe and flange can trap contaminants.
- More challenging to inspect and maintain compared to other flange types.
5. Standards:
- SW flanges are manufactured according to various standards, such as ASME B16.5, ANSI, and DIN.
6. Installation:
- Proper alignment and welding are crucial to ensure a secure and leak-free connection.
- A small gap (typically 1/16 inch) is left between the pipe and the flange shoulder to allow for thermal expansion during welding.
Socket Weld flanges are a reliable choice for high-pressure piping systems, offering durability and ease of installation in compact spaces. Let me know if you need further details!
Product shooting
Factory
Product packaging
We can provide wooden box packaging, pallet packaging, carton box packaging, and we can accept customized packaging.
FAQ
Q:Can I Get A Sample For Testing?
A:Yes, We Can Provide Free Samples, But You Need To Pay For The Shipping Cost.
Q:Is It Safe On The Payment For Me As We Are The First Cooperation?
A:We Can Do The Trade Assurance On Alibaba, Which Will Guarantee Your Payment Safety, We Also Accept Other Safe Payment Way As You Want.
Q:Do You Accept Product Customization?
A:Yes, We Can Accept Material Customization, Specification Model Customization, Drawing Customization, Packaging Customization.
Q:Can I Put Our Logo On The Product?
A:Yes, We Can Provide You With Laser Engraving Logo And Sticker Logo For Free.
Q:What Is The Moq?
A:For Trial Order, We Can Sell Even One Piece
Q:How Long Is The Product Warranty Period?
A:One Year, If The Product Is Non-Artificially Damaged During The Warranty Period, We Can Provide You With A New Product For Free.
Q:How Long Is The Delivery Time?
A:If We Have Stock, We Will Ship Within 2 Days, If There Is No Stock, We Will Ship Within 5-7 Days.
Q:Do You Accept Oem/Odm Service?
A:Yes, We Can Produce Products According To Your Requirements.
